    SK250 ATV Quads-1E

    Products Visitors:2672


    Description of SK250 ATV Quads:
    This SK250 ATV/quad is designed to meet riders' needs of durability, comforts and reliability. Different colors are available, including maple leaf, yellow-black, red-black and black-red.
    Features of SK250 ATV Quads:
    - Leading edge styling
    - Excellent fuel economy
    - Single-cylinder, 4-stroke engine
    - Electric starter
    - Approve mode: EPC, EPA, EEC
    - 6 months warranty for electric parts, one year or 8000km warranty for others.
    Technical Specification of SK250 ATV Quads:
    MODEL     SK250ATV-E1----250CC     SK200ATV-E1—200CC
    ITEM     DESCRIPTION     DESCRIPTION
    Engine type     Single cylinder,4-stroke,water-cooling     Single cylinder,4-stroke,water-cooling
    Displacement(ml)     249.6     197
    Max power (kw/r/min)     15/(7500±5%)     11.0/(7500±5%)
    Max torque ((n.m/r/min)     18/(5,500±5% )     14.2/(6000±5%)
    Compression ratio     10.5:1     9.2:1
    Bore and stroke(mm x mm)     67*65     63.5*62.2
    Ignition method     CDI     CDI
    Starting method     Electric     Electric
    Clutch method     Hand clutch     Hand clutch
    Gearshift method     5 speed, inside reverse     5 speed, inside reverse
    Max speed(km/h)     ≥85     ≥75
    Transmission     Chain drive     Chain drive
    Brake     Front disc/rear disc     Front disc/rear disc,
    Climbing ability     ≥25°     ≥25°
    Number of swing arm     Double swing arm     Double swing arm
    Front tire/rear tire     21x7-10/22x10-10      21x7-10/22x10-10
    Net weight(kg)     155     145
    Overall dimension(mm)     1800x1120x1130     1800x1120x1130
    20GP     12PCS     12PCS
    40HQ     42PCS     42PCS
    Carton size     1650*1120*860MM     1650*1120*860MM
