Voltage: DC12V
Start Current: 900mA
Standby Current: 250mA
Fail Safe/Fail Secure(adjustable)
Face Plate: 170×48×40mm
Bolt: 17mmDIA,stainless steel 13mm throw
Solid Bolt: polishing housing, .  holding force: 900kg/2400lbs.

Suitable For: 12~15mm Electric Bolt For Fully Frameless
Surface Temp: Low Temperature
Induction Distance:8mm
Door lock delay time: 0/ 2.5/ 5 seconds available to set
Signal Output: Door Status Output,NC/COM
Operating temp: -10~+25℃(14-131F)
Operating Humidity: 0~90%(non-condensing)
Special Designed: Tested to 500000 cycles
Face place material:High Aluminum,Carrulous Line Finished
Weight: 1.2kg
Standard Packing: 20pcs
