Voltage: DC12V
Start Current: 900mA
Standby Current: 150mA
Face Plate: 205Lx30WX38H(mm)
Strike plate : 100Lx25Wx3W(mm)
Bolt :17mmDIA,stainless steel 16mm throw
Solid Bolt: polishing housing, 2000Kg Holding Force
Suitable For: Woodeng Door,Glass Door,Metal Door,Glass Door
Autolock Time Delay: 0,3,6,9sec.
Signal Output: Lock status Output,NO/NC/COM
Surface Temp: Low Temperature
Suitable for 180° door.
Operating temp: -10~+25℃(14-131F)
Operating Humidity: 0~90%(non-condensing)
Special Designed: Tested to 500000 cycles
Face place material:High Aluminum,Carrulous Line Finished
Weight: 1kg
Standard Packing: 30pcs
