Balancing machine ND-XSV-5AL-II
Balancing machine ND-XSV-5AL-II
Original Image
Products Visitors:567



Main components:
Air cylinder: SMC
Servo motor: MITSUBISHI
Sensor: KEYENCE, OMRON, CONTRINEX
Touching screen: KEYENCE
PLC: KEYENCE
Stepping motor: ORIENTAL or SANYO

Armature size:
Armature weight: under 1.6kgs
Armature OD: 23-39mm or 28-44
Core length: 15-60mm



Balancing speed: 1500-2200rpm



Milling method: R-type or V-type milling cutter cylindrical milling, control the depth and length of milling

Power: 380V

Air pressure: 0.4-0.6MPa

Initial unbalance value: in accordance with armature OD and milling depth. For an example: OD32mm armature, single milling point on or below 500mg, OD40mm armature, single milling point on or below 800mg



Residual unbalance eccentricity: better than the national standard for Grade 6.3



Dimensions: 2000x1700x1800mm
