This series of Powder Coating Machine is the most technical advanced product in electrostatic coating field,which is widely used in mini rotor insulating coating, such as automotive, motorcycle, power cycle, toy and small electromotor of appliance.

Working procedure:
Small motor is transported to fluid bed by screw for coating. Insulation power is equally coated on its surface, then cured by high frequency heating.The Powder Coating Machine  consists of coating, curing, cooling and powder recycling. Except loading and unloading, the other process are completed automatically.

Main technical data:

Air source pressure: 0.5~0.7Mpa

Screw rod length: 3500mm
Recycle efficiency:  ≥95%

Feeding speed: 0~0.5RPM

Static voltage: 0~60KN
Static current: ≤200μA

Voltage: 380V, three phase

High frequency power: 30KW

Total dimension: 4900mm*2500mm*2000
