Home > Products Show > Commutator and DC Motor Machines > Four Station Armature Winding MC ND-RM-AL2-N01
|
This kind of Four Station Armature Winding Machine is used for the small armature with 3~5 slots.There are 4 working stations, 4 armature can be winded at same time
Technical parameter: 1. Armature type: 3~5 slots armature 2. Armature OD:8mm~25mm 3. Wire diameter: 0.08mm~0.55mm 4. Max.armature stack length: 30mm 5. Max.shaft length: 70mm 6. Max.spindle speed: 3000rpm 7. Working power:AC 220V+/-10% 8. Rated power: ≤1.2kW 9. Input air source: 0.4MPa≤woorking air pressure≤0.8MPa 10. Working environment temperature: 0℃~45℃ 11. Working environment humidity: 10%~60%(no condensation) 12. Machine dimension: 1100*1100*1300mm 13. Package dimension: 1200*1200*1500mm 14. Machine weight: 320kg 15. Package weight: 430kg Main spare parts: 1. One set of tools 2. Four pcswire bobbin(in which the copper wire is put) Main configuration: 1. One set PLC + touch screen 2. One set servo driver 3. Two sets stepping motor driver 4. Two sets Tanwan Mingwei switching power supply 5. One set NSK screw rod
