Home > Products Show > Commutator and DC Motor Machines > Automatic Armature Winding Machine ND-LAW-5B2
|
Armature winding machine is used for automatically hook type commutator armature winding , it is suitable for winding medium and big wire diameter armature. Automatic feeding, winding,indexing and wire cutting,only load and unload armature from material loader. Equipped with touch screen and PLC, winding parameter could be set and modified on the screen.
Technical Parameter:
Wire diameter range: 0.16~0.55 mm (magnetic hysteresis method)
0.30~0.85 mm ( electric control method) Armature diameter: 20~60 mm Stack length: 10~70 mm Shaft diameter: 3~15 mm Shaft length: less than 250mm Armature Slot:even slot Turn number: 0~9999 Commutator diameter:8~40 mm Winding speed: 0~2500 rpm Winding motor power: 1.5KW x 2 Angle detecting speed: 0~3000 rpm Angle detecting motor power: 0.75KW x 1 Air supply pressure: 4~6 Kg/cm2 The machine total power:4.0 KW Voltage:three phase AC380V 50/60 Hz Weight: 600Kg Dimension:2000(length)X1300(width)X1800(height)mm
