| Specification and technical data: | ||||||
| General | Model | CPYD25 | ||||
| Rated capacity | kg | 2500 | ||||
| Load center | mm | 500 | ||||
| Dimension | Lift height | mm | 3000 | |||
| Overall dimension | Length to fork face | mm | 2580 | |||
| Overall width | mm | 1150 | ||||
| Mast lowered height | mm | 2060 | ||||
| Overhead guard height | mm | 2060 | ||||
| Turning radius | mm | 2240 | ||||
| Performance | Travel speed (full load/no load) | Hydraulic | km/h | 17/19 | ||
| Lift speed (no load/full load) | mm/sec | 470 | ||||
| Max grade ability | % | 20 | ||||
| Engine | NISSAN K21;MITSUBISHI 4G64;BAIYANG 491 etc. | |||||
