Specifications

Parameters

Mass Scope of Workpiece (kg)

50

Max Diameter of Workpiece (mm)

700

Distance Between Two Support Bearings (mm)

Min:60

Journal Diameter Scope of Workpiece (mm)

8~80

Max Distance between Driving Flange and Right Bearing Support (mm)

1000

 Rotation Speed of the Main Axis (r/min)

800/1200/1600/2400

Motor Power (kw)

0.85/1.1

Torque of Universal Joint Shaft (N.m)

30

Min Achievable Residual Unbalance Amount (emar)

1g.mm/kg
