Specifications

Parameters

 Mass Scope of Workpiece (kg)

10000

Max Diameter of Workpiece (mm)

2800

Distance Between Two Support Bearings (mm)

Min:450

Journal Diameter Scope of Workpiece (mm)

60~400

Max Distance between Driving Flange and Right Bearing Support (mm)

3600

Rotation Speed of the Main Axis (r/min)

192/330/550/900/1350/

(Stepless Speed Regulating)

Motor Power (kw)

22(variable-frequency)

Torque of Universal Joint Shaft (N.m)

2250

 Min Achievable Residual Unbalance Amount (emar)

1g.mm/kg
