Specifications

Parameters

Mass Scope of Workpiece (kg)

160

Max Diameter of Workpiece (mm)

1000

Distance Between Two Support Bearings (mm)

Min:60

Journal Diameter Scope of Workpiece (mm)

10~140

Max Distance between Driving Flange and Right Bearing Support (mm)

1320

 Rotation Speed of the Main Axis (r/min)

315/630/570/1140

Motor Power (kw)

1.5/2.4

Torque of Universal Joint Shaft (N.m)

60

Min Achievable Residual Unbalance Amount (emar)

1g.mm/kg
