*Alternative and elegant appearance;
*Human-based design,high working efficiency,
good operation performance;
*Boom side-shift device, realizes no tail rotation;
*Smooth, quick and easy operation;
*Long working life,convenient maintenance.
Technical data:
Model
KDG55
Bucket capacity (m3)
0.16
Standard bucket width (with/without sharpener) (mm)
600/550
Operation weight (kg)
5600
Overall dimension (LxHxD) (mm)
5525x2660x1960
Engine model
KD388Z
Engine rated output (kw/r/min)
31.4/2400
Max. digging height (mm)
5615
Max. dumping height (mm)
3980
Max. digging depth (mm)
3550
Max. vertical digging depth (mm)
2810
Max. digging radius (mm)
6005
Side-shift amount for big boom(left/right) °
48/49
Min. front gyration radius (mm)
2057
Min. rear gyration radius (mm)
880
Max. digging force(bucket) (Kn)
≥15
Pedrail
Rubber
Pedrail width (mm)
300
Travelling speed (km/h)
2.5/4.7
Grade ability (%)
50
Gyration speed (r/min)
1960
Shovel mould board (width) (mm)
1770
Shovel mould board (height) (mm)
330
Lifting distance (up/down) (mm)
565/285
Hydraulic pump
Variable plunger pump x 2 + Gear pump x 1
Rotary motor
Cycloidal hydraulic motor
Travelling motor
Plunger hydraulic motor
Fuel tank capacity ( L)
40
