Properties

Typical Data

Test Methods

Tensile Strength

≥12MPa

ASTM D 2671

Elongation

≥400%

ASTM D 2671

Tensile Strength After Heat Aging

≥8MPa

160°C×168h

Elongation After Heat Aging

≥220%

160°C×168h

Longitudinal Change

-8%~+8%

ASTM D 2671

Dielectric Strength

≥15kV/mm

IEC 60243

Fluid Resistance Tensile Strength

≥10MPa

ISO 37 24hrs.(diesel 70°C,hydraulic 70°C, lubricant 100°C)

Fluid Resistance Elongation

≥300%

Flammability

VW-1

UL 224

Heat Shock

No crack,no dripping

215°C×4h

Sizes

I.D. As Supplied D(mm)

Sizes After Full Recovery(mm)

Standard Package (m/spool)

I.D. d

Wall Thickness w

Φ3.2

≥3.2

≤1.6

0.76±0.15

200

Φ4.8

≥4.8

≤2.4

0.84±0.15

100

Φ6.4

≥6.4

≤3.2

0.89±0.15

100

Φ9.5

≥9.5

≤4.8

1.02±0.20

50

Φ12.7

≥12.7

≤6.4

1.22±0.20

30

Φ19.0

≥19.0

≤9.5

1.45±0.28

30

Φ25.4

≥25.4

≤12.7

1.78±0.28

30

Φ38.1

≥38.1

≤19.0

2.41±0.41

15

Φ50.8

≥50.8

≤25.4

2.79±0.41

15

Φ76.0

≥50.8

≤38.0

3.18±0.50

15
