Test Properties

Typical Data

Test Method

Tensile Strength

≥13 MPa

ASTM D 2671

Ultimate elongation

≥300%

ASTM D 2671

Tensile strength after thermal aging

≥10 MPa

120℃, 168 hrs

Ultimate elongation after thermal aging

≥250%

150℃, 168 hrs

Dielectric Strength

≥15kV/mm

IEC 60243

Volume Resistivity

≥10¹³Ω .cm

IEC 60093

Size

(mm)

Big end ID(mm)

Finger ID(mm)

Length

(±10%)

Thickness after shrink

(±20%)

Before shrink

After shrink

Before shrink

After shrink

Total Length

Finger Length

Big end

Thickness

Finger

Thickness

Two cores cable breakout

Φ22/8

22

8

9

3.5

55

18

2.2

1.8

Φ30/12

30

12

14

4.5

93

23

2.6

2.2

Φ40/16

40

16

15

5

125

35

2.1

2.1

Φ60/23

60

23

25

7.5

118

29

2.6

2.6

Φ60/23

60

23

25

7.5

155

45

2.6

2.6

Φ100/42

100

42

30

9

155

55

3.1

3.1

Φ150/75

150

75

20

6

170

64

3.8

3.8

Three cores cable breakout

Φ38/16

38

17

14

4..5

98

23

2.7

2.7

Φ40/16

40

16

15

4.5

125

35

2.1

2.1

Φ60/24

60

25

25

8

165

50

3.0

2.5

Φ60/24

60

24

25

8

180

45

3.2

2.8

Φ80/36

80

38

35

11

185

55

3.5

3.5

Φ80/36

80

38

35

11

215

57

4.0

4.0

Φ110/48

110

50

46

17.5

250

65

4.0

4.0

Φ125/57

125

57

55

20

260

57

4.0

4.0

Φ140/70

140

70

62

26

280

70

4.0

4.0

Φ170/75

170

77

75

28

280

80

4.0

4.0

Four cores cable breakout

Φ40/15

42

15

14

3.5

105

26

2.2

2.0

Φ55/21

55

21

20

5

150

40

3.1

2.6

Φ65/26

65

26

26

7

175

45

3.3

2.9

Φ75/26

75

26

28

7

175

45

3.3

2.9

Φ82/37

82

37

30

9

190

60

4.0

3.0

Φ90/37

90

37

32

9

190

60

4.0

3.0

Φ100/47

102

47

38

12

198

58

4.0

3.0

Φ125/52

130

52

52

15

240

75

4.0

4.0

Φ160/70

160

70

64

19

260

75

4.0

4.0

Five cores cable breakout

Φ40/19

40

19

13

4

98

25

2.5

2.0

Φ55/24

55

24

18

5

155

40

3.2

2.6

Φ80/33

80

33

26

8

175

53

3.0

2.8

Φ100/42

100

42

34

10

190

60

3.0

3.0
