Property

Typical data

Test Method

  Tensile strength

≥8.0MPa

ASTM D 2671

     Elongation at break

≥300%

ASTM D 2671

      Tensile strength after heat aging

≥6.9MPa

130℃×168   h

       Elongation after heat ageing

≥100%

130℃×168h

        Longitudinal change

-8%～+8%

ASTM D 2671

        Flammability(Oxygen index)

≥28

GB/T 2406

Heat Shock

No tracks

JB 7829

    Dielectric Strength

≥20kv/mm

ASTM D 149

  Shore A Hardness

≤90

GB2411

   Volume resistivity

≥10¹⁴Ω.cm

IEC 60093

Size(mm)

As supplied D(mm)

After full recovered (mm)

Standard package

(M/Roll)

Inner diameter d

Wall thickness w

Φ15/6

≥15

≤6.0

2.5±0.20

50

Φ20/8

≥20

≤8.0

2.5±0.20

50

Φ25/10

≥25

≤10.0

2.5±0.20

50

Φ30/12

≥30

≤12.0

2.5±0.20

25

Φ40/16

≥40

≤16.0

2.8±0.30

25

Φ50/20

≥50

≤20.0

2.8±0.30

25

Φ65/26

≥65

≤26

2.8±0.30

25

Φ75/30

≥75

≤30

2.8±0.30

25

Φ85/34

≥85

≤34

2.8±0.30

25

Φ100/40

≥100

≤40

2.8±0.30

25

Φ120/48

≥120

≤48

2.8±0.30

25

Φ150/60

≥150

≤60

2.8±0.30

25

Φ180/72

≥180

≤72

2.8±0.30

25

Φ210/84

≥210

≤84

2.8±0.30

20

Φ230/92

≥230

≤92

2.8±0.30

20

Φ250/100

≥250

≤100

2.8±0.30

20

Φ300/120

≥300

≤120

2.8±0.30

15
