Feature:
1.The imported programmable controller, servomotor, super large display touch screen are the driving and control center of this machine. The machine is featured with good performance, simple operation.
2.The machine and metering device can finish automatically all packing processes, i.e. measuring, feeding, filling and bag making, date stamp, finished product transfer.
3.The complete automatic alarm protection function can reduce the waste to minimum and assist the operator to remove the faults in time.
4.The machine adopts intelligent temperature controller and two independent sealing cylinder, which can guarantee the top seal looked good and smooth.
Specifications:
Air consumption
2.5m3/min,6kg/cm2
Film width
160-420 mm
Film roll dia.
max.360mm
Film material
plastic expect PE
Film thickness
0.04-0.08 mm
Bag width
80-200 mm
Bag length
80-300 mm
Packing speed
5-70 bags/min
Packing range
max.1000ml
Power
220V,50/60Hz,3kw
Options:
1.Filling machine:
Auger type filling machine
Measuring cup filling machine
Semi-automatic feeding device
Electronic weighing system
2.material elevator:
Z type bucket chain material elevator
screw conveyer
stainless steel hopper material elevator
3.sealing form
center sealing bag/back sealing bag (standard)
gusset bag/stand bag
linking bags
bags with holes
