Suitable for packing the goods with irregular shape or hard automatic metering,such as potato chips,tomatio chips,jelly,dumpling,steam bread chips,instant noodles and so on.
Feature:
1.The imported programmable controller, servomotor, super large display touch screen are the driving and control center of this machine. The machine is featured with good performance, simple operation.
2.The machine and metering device can finish automatically all packing processes, i.e. measuring, feeding, filling and bag making, date stamp, finished product transfer.
3.The complete automatic alarm protection function can reduce the waste to minimum and assist the operator to remove the faults in time.
4.The machine adopts intelligent temperature controller, which can guarantee the top seal looked good and smooth.
5.Manual metering,suitable to packing mix goods.
6.No empty bags will be delivered when there is no material,less waste.
7.This machine set is economical and practical.
Specifications:
Air consumption | 2.5m3/min,6kg/cm2 |
Film width | 160-420 mm |
Film roll dia. | max.360mm |
Film material | OPP/CPP,OPP/CE,MST/PE/PET/PE |
Film thickness | 0.04-0.08 mm |
Bag width | 80-200 mm |
Bag length | 80-300 mm |
Packing speed | 5-70 bags/min |
Packing range | max.1000ml |
Power | 220V,50/60Hz,2.4kw |
Options:
1. Nitrogen gas flushing
2. Vacuum packing device
3. Flip device
4. Gusset device
5. Hole punch device
6. Tear notch device
7. PE sealing system
8. Finished product conveyor
9. Air compressor
