Suitable for packing the goods with irregular shapes and requiring high measuring accuracy such as frozen dumplings,candy,sweet,fruit flakes,potato chips,tomato chips,biscuits,cookies,nuts,beans,seeds,sugar,salt,mini-bag rice,puffed food and so on.
Feature:
1.The imported programmable controller, servomotor, super large display touch screen are the driving and control center of this machine. The machine is featured with good performance, simple operation.
2.The machine and metering device can finish automatically all packing processes, i.e. measuring, feeding, filling and bag making, date stamp, finished product transfer.
3.The complete automatic alarm protection function can reduce the waste to minimum and assist the operator to remove the faults in time.
4.The machine adopts intelligent temperature controller, which can guarantee the top seal looked good and smooth.
5.High accuracy with fast speed,high efficiency and no broken material.
6.Save labor cost,less waste,easy operation and maintainance.
Specifications:
Air consumption | 2.5m3/min,6kg/cm2 |
Film width | 160-420 mm |
Film roll dia. | max.360mm |
Film material | plastic expect PE |
Film thickness | 0.04-0.08 mm |
Bag width | 80-200 mm |
Bag length | 80-300 mm |
Packing speed | 5-70 bags/min |
Packing range | max.1000ml |
Power | 220V,50/60Hz,2.4kw |
Optional devices:
1. Nitrogen gas flushing
2. Vacuum packing device
3. Flip device
4. Gusset device
5. Hole punch device
6. Tear notch device
7. PE sealing system
8. Finished product conveyor
9. Air compressor
