Suitable for packing the goods with irregular shapes but requiring high accurate measuring,such as potato chips,tomato chips,fruit flakes,biscuit,candys,dumpling,nuts,fried food and so on.
Feature:
1.This machine is featured with compact structure,stable,simple operation,convenient on repairing.
2.PLC system with large touch screen,visual and understandable.
3.Servomotor control film conveyer system with accurate position,makes the bag forming smooth.
4.This machine can finished from feeding,date printing,measuring,filling,making bag,cutting in one operation.
5.It is a high measuring accuracy,high efficiency machine,less labor,less waste but easy operation and maintainance.
Specifications:
Air consumption | 2.5m3/min,6kg/cm2 |
Film width | 120-380 mm |
Film roll dia. | max.300mm |
Film material | plastic expect PE |
Film thickness | 0.04-0.08 mm |
Bag width | 50-180 mm |
Bag length | 80-240 mm |
Packing speed | 5-70 bags/min |
Packing range | max.800ml |
Power | 220V,50/60Hz,2.4kw |
Options:
1. Nitrogen gas flushing
2. Vacuum packing device
3. Flip device
4. Gusset device
5. Hole punch device
6. Tear notch device
7. PE sealing system
8. Finished product conveyor
9. Air compressor
