Sutiable for packing the goods which are hard to automatic metering or the frangible goods such as potato chips,flakes,jelly,dumpling,crispy,gift and so on.
Feature:
1.This machine is featured with compact structure,stable,simple operation,convenient on repairing.
2.PLC system with large touch screen,visual and understandable.
3.Servomotor control film conveyer system with accurate position,makes the bag forming smooth.
4.Manual metering,suitable for packing several kinds of goods in one pack.
5.No empty bags will be delivered when there is no material,less waste.
6.It is a economical and practical machine set.
Specifications:
Air consumption
2.5m3/min,6kg/cm2
Film width
120-380 mm
Film roll dia.
max.300mm
Film material
OPP/CPP,OPP/CE,MST/PE/PET/PE
Film thickness
0.04-0.08 mm
Bag width
50-180 mm
Bag length
80-240 mm
Packing speed
5-70 bags/min
Packing range
max.800ml
Power
220V,50/60Hz,2.4kw
Options:
1. Nitrogen gas flushing
2. Vacuum packing device
3. Flip device
4. Gusset device
5. Hole punch device
6. Tear notch device
7. PE sealing system
8. Finished product conveyor
9. Air compressor
