ND-QDC-200 Starting motor performance tester

suitable for auto starting motor performance tests, print and save characteristics and parameters, with absorption voltage, release voltage, unload performance, load performance, braking performance, electricity break performance, over speed test.

Composed with testing bracket, computer testing platform, high precision and big power switch simulation power supply etc.

Power Supply Voltage: 3Φ-380V±10% 50Hz

Air source Pressure: 0.5~0.7Mpa

Main Specifications:

0~15V/200N.m/900A/12000r/3kw magnet powder

0~30V/400N.m/1500A/12000r/5kw magnet powder

0~30V/1500N.m/1800A/12000r/8kw magnet powder plus brake

0~30V/2500N.m/3000A/12000r/10kw magnet powder
