ND-SHJ-5 Double cutter Commutator Precise Lathing Machine

Suitable for motor commutator high precision automatic lathing

PLC control, rough lathing, precise lathing finish in one time, three sets of beeline rolling beads guiding rod, imported damp device adjusting path knife speed.

Power Supply Voltage: 220V±10%  50Hz

Air source Pressure: 0.5~0.7Mpa

Power: 750W

Workpiece Line Speed: 0~400m/min

Rotor Shaft Diameter: Φ2～Φ16mm

Rotor Outer Diameter: Φ28～Φ80

Surface Roughness: Ra0.4

Commutator Length: ≤28mm
