ND-SK-21 Double Coil Armature Wire Embedding Machine

Suitable for automatic wire embedding of open slot double coils armature winding that shaped to W shape.

Use hydraulic and mechanism combination design, PLC, embed shaped W coil to commutator, no need to twist head, finish directly.

Power Supply Voltage: 3Φ-380V  50Hz

Motor Power: 2.2KW

Wire Diameter: Φ1.5-Φ2.5mm

Slot Number Suitable: 21 slots (can be made specially)

Armature Diameter Suitable:135mm

Armature Height Suitable:480mm
