Horizontal Stator Insulation Paper Inserting mc


ND-CW200 horizontal paper inserting machine

Especially suitable for paper inserting to the stator of large and medium-size motors such as generator, deep pump motor, three phase machine etc.

Automatic paper feeding, edge folding and forming and inserting; characterized by low noise, fast speed, excellent forming etc; slot-skipping paper inserting and slot-by-slot paper inserting could be set up in the HMI.

1. Stator ID

80-150mm

2. Stator OD

210mm

3. Stack hickness

60-190mm

4. Paper folded width

3-7mm

5. Max paper thickness

0.35mm

6.Paper feeding length

15-50mm

7. Working efficiency

0.7-1S/slot

8. Power

380V 50HZ, 0.75KW

9.Weight

550KG

10. Dimension

1100 X 900 X1500mm
