Coil Pre-forming Machine ND-KZ160
Coil Pre-forming Machine ND-KZ160
Original Image
Products Visitors:705



ND-KZ160 Pre-forming machine

Driven by hydraulic system; PLC program ;tooling expansion blade makes the first coli and inter-phase insulation paper in tight array to leave enough space for second insertion and ensure the quality of successive coil insertion; apply to multi-layer stator winding insertion.

1. Stator ID

30-100mm

2. Stator OD

≤160mm

3. Stack thickness

15-100mm

4. Output volume of oil cylinder

20F

5. Power

380V/50Hz, 1.5KW

6. Weight

800kg

7. Dimension

1200 X 700 X2200mm
