Final Forming Machine ND-ZZ160
Final Forming Machine ND-ZZ160
Original Image
Products Visitors:640



ND-ZZ160 final forming machine

Driven by hydraulic system; PLC program; tooling design adopts flexible principles of inner expansion, outer wrapping and edge forming to forming the stator winding to ensure appropriate winding outside dimension after lacing.

1. Stator ID

50-100mm

2. Stator OD

≤160mm

3. Stack thickness

16-100mm

4. Output volume of oil cylinder

20F

5. Power

380V/50Hz, 1.5KW

6. Weight

700kg

7.Dimension

650 X 900 X2300mm
