Die Casting Machine ND-ZL100
Die Casting Machine ND-ZL100
Original Image
Products Visitors:939



ND-ZL100 die casting machine

Suitable for casting the aluminum rotor of small size;


4 working stations; it does the loading, working table rotation, casting, scratch removing, rotor cooling, unloading automatically. Parameters could be set in HMI.

1. Rotor OD

40-80mm

2. Stack thickness

16-100mm

3. Max casting weight

0.6kg

4. Rotor core

Without opening slot

5. Working pressure of upper cylinder

40T

6. Working pressure of lower cylinder

12T

7. Max working pressure of liquid aluminum

22.6Mpa

8. Oil tank capacity

425L

9. Running speed of pressing and shooting piston

Slow shooting190mm/s, fast shooting600mm/s

10. Hydraulic system

40L variable piston pump with 7.5KW motor

11. Working efficiency

8S

12. Power

380V/50Hz, 8.5KW

13. Weight

2000kg

14. Dimension

1800 X 1800 X2350mm
