Specifications
|
Item Model |
YVM-1510W |
YVM-2010W |
|
X.Z Axis Travel |
150* |
200* |
|
Y Axis Focusing Travel |
|
|
|
X.Z Axis Resolution |
|
|
|
Accuracy |
(3+L/250)um |
|
|
Total Magnification |
24X~156X (12-312X is available) |
|
|
CCD |
0.43Mpixel high definition Sony Chip CCD |
|
|
Measuring Software |
Special Vision measuring software YR-CSPC |
|
|
Instrument Base |
000 grade stable granite base |
|
|
Illumination |
Surface and contour illumination both use brightness adjustable LED shadowless lamp |
|
|
Machine Weight |
140Kgs |
150Kgs |
