Single line rated pull

10000lb(4536kg)

Motor

6.0 hp/4.5kw.Series Wound

Main body

Sealed

Control

Remote switch,12ft(3.7m)lead

Remote Control

Included

Gear train

3 Stage Planetary

Gear reduction ratio

191:1

Clutch

Keyway Cam

Braking Action

Automatic braking action in the drum

Cable

28m of 9.1mm diameter

Fairlead

4-way roller fairlead

Battery

Recommended: 650CCA minimum for winching

Battery Leads

2 gauge,72"(1.83mm)

Finish

Powder coating

Weight

N.W. 36kgs  G.W 38kgs

Overall dimensions

(L*W*H) 526.3x160x179mm

Mounting Bolt Pattern

10” x 4.5” (254x114.3mm)

Line Pull

Lbs

NO

LOAD

2000

4000

6000

8000

10000

kgs

909

1814

2721

3629

4536

Line Speed

ft/min

35.50

20.60

15.19

12

9.84

8.07

m/min

10.82

6.28

4.63

3.66

3.0

2.46

Motor Current

amps

67

131

198

261

320

365

Layer of cable

1

2

3

4

Rated line

pull per layer

Lbs

10000

8000

6670

5720

Kgs

4536

3629

3025

2595

Cumulative

Cable capacity

Ft

21.3

40

72.0

92

M

6.5

12

22

28
