Single line rated pull

8500lb(3856kg)

Motor

5.6 hp/4.1kw.Series Wound

Main body

Sealed

Control

Remote switch,12ft(3.7m)lead

Remote Control

Included

Gear train

3 Stage Planetary

Gear reduction ratio

230.4:1

Clutch

Sliding ring gear

Braking Action

Automatic braking action in the drum

Cable

28m of 8.1mm diameter

Fairlead

4-way roller fairlead

Battery

Recommended: 650CCA minimum for winching

Battery Leads

2 gauge,72"(1.83mm)

Finish

Powder coating

Weight

N.W. 35kgs  G.W 37kgs

Overall dimensions

(L*W*H) 538*160*214mm

Mounting Bolt Pattern

10” x 4.5” (254x114.3mm)

Line pull  lb(kg)

Line speed ft/min(m/min)

Current (A)

0

22(6.8)

60

2000(907)

15.7(4.8)

113

4000(1814)

12(3.6)

184

6000(2721)

9(2.8)

228

8500(3856)

6.2(1.9)

301

Layer of cable

1

2

3

4

Rated line

pull per layer

Lbs

8500

6620

5630

4850

Kgs

3856

2980

2534

2183

Cumulative

Cable capacity

Ft

23.3

47

80

92

M

7.1

14.5

24

28
