Specification:

Model: PUB-V901-Z-WS

 Image  Sensor

 Image Sensor

1/4" Color CMOS Sensor

 Display Resolution

640 x 480 Pixels(300k Pixels)

 Lens

3x Optical Zoom(4mm-9mm)

 Mini. Illumination

0.5Lux, F2.0

 Lens Type

Glass Lens

 Viewing Angle

30.7°~ 69°

 Audio

 Input

1 channel audio input

 Output

1 channel audio output

 Audio Compression

ADPCM

 Video

 Image Compression

MJPEG

 Image Frame Rate

15fps(VGA),30fps(QVGA)

 Resolution

640 x 480(VGA), 320 x 240(QVGA)

 Flip Mirror Images

Vertical / Horizontal

 Light Frequency

50Hz, 60Hz, Outdoor

 Video Parameters

Brightness, Contrast

 Communication

 Ethernet Interface

10Base-T/100Base-TX Ethernet Port

 Supported Protocol

TCP/IP, DHCP, SMTP, HTTP, DDNS, UPNP, PPPoE, FTP, DNS

Wireless Standard

IEEE 802.11b/g

Data Rate

802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.)

Wireless Security

WEP & WPA WPA2 Encryption

 Physical

 Pan/Tilt Angle

Horizontal:355° & Vertical: 90°

 Alarm Input

1 Channel on/off Input

 Alarm Output

1 Channel relay Output

 Dimension

165*195*130 mm

 Power

 Power Supply

DC 12V/2.0A (EU,US adapter or other types optional)

 Power Consumption

8 Watts (Max.)

 Environment

 Operate Temper.

0° ~ 55°C

 Operating  Humidity

20% ~ 85% non-condensing

 Storage Temper.

-25°C ~ 55°

 Storage Humidity

0% ~ 90% non-condensing

   PC System Requirements

 CPU

2.0GHZ or above (suggested 3.0GHz)

 Memory Size

256MB or above (suggested 1.0GHz)

 Display Card

64M or above

 Supported OS

Microsoft Windows 2000/XP/Vista/7

 Browser

IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers

  Certification

 CE, FCC, RoHS

  Warranty

 Limited 1-year warranty
