Model No.: PUB-V012-WS-A
Catalogue |
Type |
Parameters |
Features |
View by phone |
Support monitoring via mobile devices on line(such as iOS、Android OS、Symbian OS、WindowsPhone7) |
Mobile Platform |
No need to install software, Multi-screen monitoring and managing by mobile phone,alarming,viewing. |
|
View on PC |
Internet Explorer 6.0 or higher version,firefox,chrome |
|
Super Client |
1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm |
|
System |
Operation system |
Embedded Linux OS |
System security |
Supports three-level account, password, user multi-level authority management |
|
DDNS |
Provide DDNS for free ,like demo.gocam.so |
|
Collection |
Image sensor |
0.3MegaPixel Color CMOS Image Sensor |
SNR |
≥45dB |
|
Minimum Illumination |
0.3Lux |
|
3A |
Auto White Balance,Auto Exposure,Automatic Gain |
|
Lens |
Standard:3.6mm |
|
Video |
Compression Format |
Motion-JPEG |
Resolution |
VGA(640×480)/QVGA(320×240) |
|
Maximum frame rate |
25fps |
|
Bit Rate |
32Kbps~4Mbps |
|
Adjustment |
light intensity,contrast ratio,saturation level are adjustable. |
|
Nightvision |
Effects |
12 Φ5 LEDs IR distance:15m |
Audio |
Encode formats |
ADPCM |
Input |
Built in microphone |
|
Output |
one channel linear output,normal connector Of3.5mm |
|
Network |
Socket |
RJ-45 10/100Mb self-adaptable Ethernet slot |
Protocol |
TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,PPPoE , etc |
|
WIFI |
WIFI 802.11 b/g/n |
|
Visitors Online |
Support 4 visitors viewing on line at the same time |
|
Alarm |
Alarm Detection |
Support motion detecting ,Settings for sensitivity detection |
Alarm action |
E-mail pictures /upload video by FTP/messages alarm(coordinate to server) |
|
Physical index |
Power |
DC 5V |
Comsumption |
<6W |
|
Temperature |
-10~50℃ |
|
Humidity |
10%~85% |
|
Weight |
Gross:648g(Note: in kind prevail) |
|
Body Size |
85 x 85 x46.5mm(L*W*H) |
|
Package size |
170 x170x170mm(L*W*H) |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() | |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
