Catalogue

   Type

Parameters

Features

View by phone

Support monitoring via mobile devices on line(such as iOS、Android OS、Symbian OS、WindowsPhone7) Support Mac and windows pc

Mobile Platform

No need to install software, Multi-screen monitoring and managing by mobile phone,alarming,viewing.

View on PC

Internet Explorer 6.0 or higher version，firefox，chrome,safri

lLocal Memory

Support 32GTF Cards

Super Client

1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm

System

Operation system

Embedded Linux OS

System security

Supports three-level account, password, user multi-level authority management

DDNS

Provide DDNS for free ,like demo.gocam.so

Collection

Image sensor

1/4inch 0.3 Megapixel line by line CMOS sensor

SNR

≥50dB

Minimum Illumination

0.3Lux

3A

Auto White Balance,Auto Exposure,Automatic Gain

Lens

Standard：3.6mm

Video

Compression Format

H.264

Resolution

VGA（640×480）/QVGA(320×240)

Maximum frame rate

25fps

Bit Rate

32Kbps～4Mbps can be set

Adjustment

light intensity,contrast ratio,saturation level are adjustable.

Night vision

IR-CUT

Built in IRCUT，no color cast in day,clearer images at night

Effect

10 Φ5mmLEDs   IR Distance:10 m

Audio

Encode formats

ADPCM

Input

Built in Microphone

Output

one channel linear output,normal connector Of3.5mm

Memory

Memory Socket

Automatic pop-up slot for SD card

View by SD Card

Remote browsing, download of content from32Gtf card

Network

Socket

RJ-45   10/100Mb   self-adaptable Ethernet slot

Protocol

TCP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPnP，RTSP，PPPoE , etc

WIFI

WIFI 802.11 b/g/n

Visitors Online

Support 8 visitors viewing on line at the same time

P/T

Control Method

Pan:270°,Tilt：90°(speed can be set)Highest speed：70°/s

Alarm

Alarm Detection

Support motion detecting / 1 way input triggered

Alarm action

1 way output/E-mail pictures /upload video by FTP/messages alarm（coordinate to server)

Physical index

Power

DC 5V2A

Comsumption

<6W

Temperature

-10~50℃

Humidity

10%~85%

Weight

Gross：656g  （Note: in kind prevail）

Package size

200*120*179mm(L*W*H)
