| Shanghai Diesel Engine Co.,LTD. Import & Export Company | Cylinder No.: 4 | Displacement: 5.3 L | ||||||
| Bore/Stroke:114/130 mm | Compression Ratio:17.3:1 | |||||||
| Model | Unit | SC5D108D | SC5D122D | SC5D145D | ||||
| Rated Power (12h) | kW | 72 | 82 | 95 | ||||
| Standby Power(1h) | kW | 80 | 90 | 105 | ||||
| Rated Speed | r/min | 1500 | 1500 | 1500 | ||||
| Fuel Consumption @ Rated Condition | g/kW . h | ≤215 | ≤210 | |||||
| Type | Turbocharger | TCI | ||||||
| Noise | dB(A) | ≤112 | ||||||
| Oil Capability | L | 17.5 | 18 | |||||
| Cooling Water Capability(Only in Engine) | L | 5.5 | 5.8 | |||||
| Exhaust Smoke(Bosch) | Rb | ≤2.0 | ||||||
| Exhaust Temperature(After Turbocharger) | ℃ | ≤600 | ||||||
| Governor type | Electronical | |||||||
| Stable State Rate | % | 0~5% | ||||||
| Wave Rate | % | ≤0.5 | ||||||
| Speed Settling Time | S | ≤5 | ≤3 | |||||
| Starting | Electronical DC24V | |||||||
| Oil Consumption | g/kW. h | ≤0.6 | ||||||
| Min. Idle speed | r/min | ≤750 | ≤700 | |||||
| Crankshaft Rotation | Anticlockwise | |||||||
| Overall Dimension(plastic/wooden case) | mm | 1600*980*1500/ 1700*1180*1550 | ||||||
| Net weight | kg | 800 | 850 | |||||
| Dissipation Square | m² | 30 | 34.8 | 40 | ||||
| Power Station | 58kW/50HZ | 68kW/50HZ | 80kW/50HZ | |||||
| Flywheel/Flywheel Case | Flywheel SAE11 1/2#;Flywheel Casing SAE2#;Starting Gear Teeth:145 | |||||||
| Rated Speed at 1800r/min | Power(12h) | kW | 84 | 98.4 | 114 | |||
| Power Station | 70kW/60HZ | 83kW/60HZ | 94kW /60HZ | |||||
