| Shanghai Diesel Engine Co.,LTD. Import & Export Company | Bore/Stroke:120.7/152.4 mm | Cylinder No.: 6 | |||
| Compression Ratio:15:1 | Displacement: 10.45 L | ||||
| Model | Unit | SC11C300D | SC11C350D | ||
| Rated Power (12h) | kW | 200 | 225 | ||
| Standby Power(1h) | kW | 221 | 248 | ||
| Rated Speed | r/min | 1500 | 1800 | 1500 | |
| Fuel Consumption @ Rated Condition | g/kW . h | ≤215 | ≤210 | ||
| Type | Turbocharger,Water-air Intercooler | Turbocharger Air-air Intercooler | |||
| Noise | dB(A) | ≤114 | |||
| Emission | JB8891-1999 《Emission Limit for Middle-small Power Diesel Engine》(details are as attachment) | ||||
| Oil Capability | L | 27.5 | |||
| Cooling Water Capability(Only in Engine) | L | 20 | |||
| Exhaust Smoke(Bosch) | Rb | ≤2.5 | ≤2.0 | ||
| Exhaust Temperature(After Turbocharger) | ℃ | ≤600 | |||
| Governor type | Electronic | ||||
| Stable State Rate | % | 0~5% | |||
| Wave Rate | % | ≤0.5 | |||
| Speed Settling Time | s | ≤5 | |||
| Starting | Electronic DC24V | ||||
| Oil Consumption | g/kW. h | ≤0.7 | |||
| Min. Idle speed | r/min | ≤800 | |||
| Fan heat dissipating Capacity | kW | 136 | 146 | ||
| Crankshaft Rotation | Anticlockwise | ||||
| Overall Dimension | mm | 1560*992*1559 | 1500*992*1559 | ||
| Net weight | kg | 1300 | 1500 | ||
| Dissipation Square | m2 | 54.84 | 62.3 | ||
| Power Station | 180kW/50HZ,60HZ | 200kW/50HZ | |||
| Flywheel/Flywheel Case | Flywheel SAE14#;Flywheel Casing SAE1#;Starting Gear Teeth:156 | ||||
