Application
Grain Seed Cleaner/Classificator is the basic and popular Cleaning Machine in Grain and Seed Processing Line, which is suitable for cleaning all kinds of Grains, Seeds, Cereals, Crops and Flour such as Wheat, Corn/Maize, Bean(Soybean, Mung Beans, Coffee Bean Peeling, Cocoa Bean, Lentils, Cacao), Peanut/Groundnut, Paddy, Rice, Sesame, Sorghum, Sunflower, Cumin, Pepper, Oil Seeds, Flour etc. from Dust and Light Impurities. It is widely used in Grain Processing Center, Seed Processing Bases, Farm, Feed Factory, Grain Purchasing Networks, Seed Company, Seed Breeding etc.
Working Principle
Dust and Light Impurities are removed by Aspiration Fan, all the oversize and undersize impurities were discharged from outlets. The Wheat Seeds, Pepper Seeds, Rice Seeds etc. which are cleaned will fall on Sieve Layers and directly separated by Sieves according to width and thickness. The customized Sieve Layers make the Grain and Seed much cleaner and grader.
Model
Capacity
(t/h)
Power
(kw)
Weight
(kg)
Dimension
(mm)
Clean Rate
Sieve Layer
5FX-10E
10
9
1650
4800*1700*2300
97%
3
5FX-15E
15
13.74
2250
5170*2180*2400
97%
3
5FX-20E
20
17.6
2500
5170*2280*2400
97%
3
5FX-25E
25
17.6
2700
5170*2430*2400
97%
3
5FX-30E
30
19.1
2800
5170*2530*2400
97%
3
