Step motor with an angle change function
TP210+ can mount 45°, 90°,180° angle component.

Dual Parallel square-type wide guiderail
Compared with balling guiderail, the guiderail has a small space to ensure precision accuracy.

Visional+ machinery position system
Camera nearby mounting head can magnifying ' + ' cursor to make Mark point position more accurate

No-contact flying centering system
Flying centering system can mount most of SMD components include: 0603, 0805,1206 etc and SOP, SOIC (size under 15*15mm, PIN foot less than 24)

Flexible reference point system(RPS):
In addition to standard Round reference point, square PCB pad and ring PCB pad with hole also can be identified as a reference point.

All-purpose automatic feeder
22 pcs at most of automatic feeder, 8mm, 12mm,16mm, 24mm, you can choose to install according to your component type and your required speed.
it uses unique Air suspended pick-and - place head design which can transmission several kinds of large and small component.

Protel file of component data import
Software control, limitless data file can save in PC, you can call them at any time when you need, easy to operate.
