Product Code |
|
Input Voltage range |
88~132V AC/176~264V AC selected by switch 47~63Hz; 248~370V DC |
Rated DC voltage |
105ºC |
OUTPUT Voltage tolerance |
About 12V |
Protections |
Short circuit |
Test |
100% full load test |
Input current |
2.2A/115V 1.1A/230V |
Output watts |
60/ 100/ 150W |
Ripple & Noise |
<120mVp-p |
Power Factor |
>0.6 |
Efficiency (Typ.) |
>75% |
Leakage current |
0.5mA/240V AC |
Working TEMP. |
-10ºC~60ºC,20%~90% RH |
Storage TEMP. |
-20ºC~85ºC,20%~90% RH |
Safety standards |
UL 1012 TUV EN 60950 (IEC950,UL1950) Approved |
Vibration |
10~500Hz,-2G 10min/1cycle, Period for 60min,Each axes |
TEMP. coefficient |
Tolerance 0.03%/ºC(0~50ºC) |
MTBF |
20KHours MIL-HDBK-217F (25ºC) |
Dimension |
159 x 97 x 38 mm |
Weight |
560g |
Expected Life |
2-year warranty |
Certifications |
CE and RoHS |
