2. High accuracy in size.
The bonded magnet may be formed into magnetic components of relatively complicated shapes.
3. Single-time molding and multi-poles orientation.
4. The injection molded magnet has a high mechanical strength and may be molded together with other matching parts.
5. Effective surface treatment to prevent corrosion.
Good corrosion-resistance and nice surface: The product is coated with epoxy resin parylene-coating and the anti-corrosion is very good. The surface is smooth, clean and nice-looking. No bubble, no crack, no strip-off, and no chip.
6. Stable working temperature.
The working temperature is high up to 150℃.
7. Excellent magnetic properties.
The energy product is 3 times as large as anisotropic ferrite. The intrinsic coercive force is high. During the large-scale production, the magnetic properties are stable and the conformity is good.
8. Application to Bonded NdFeB.
Widely applied in all kinds of mini-motors, auto motors, air-conditioner motors,automatic controlling devices, sensors,drivers,telecom and instrument industry.
Magnetic Properties of compression molding bonded NdFeB Magnets:
Grade |
BNP-6 |
BNP-8 |
BNP-10 |
BNP-12 |
BNP-8H |
|
Br (T) |
0.52-0.60 |
0.60-0.65 |
0.65-0.70 |
0.70-0.76 |
0.55-0.62 |
|
HcB |
KA/M |
304-360 |
360-440 |
360-464 |
424-480 |
400-480 |
KOe |
3.8-4.5 |
4.5-5.5 |
4.5-5.8 |
5.3-6.0 |
5.0-6.0 |
|
HcJ |
KJ/m3 |
640-800 |
640-960 |
650-960 |
650-880 |
960-1280 |
KOe |
8.0-10 |
8.0-12 |
8.0-12 |
8.0-11 |
12-16 |
|
(BH)Max |
KJ/m3 |
40-56 |
56-72 |
72-80 |
80-96 |
48-72 |
MGOe |
5-7 |
7-9 |
9-10 |
10-12 |
6-9 |
|
Density (g/cm3) |
5.3-5.8 |
5.6-6.0 |
5.8-6.1 |
6.0-6.2 |
5.6-6.0 |
|
a Br (%/℃) |
-0.13 |
-0.13 |
-0.07- -0.105 |
-0.13 |
-0.07- -0.13 |
|
Tw (℃) |
140 |
140 |
120 |
130 |
130 |
