Single line rated pull

8500lb(3856kg)

Motor

5.6 hp/4.1kw.Series Wound

Main body

Sealed

Control

Remote switch,12ft(3.7m)lead

Remote Control

Included

Gear train

3 Stage Planetary

Gear reduction ratio

191:1

Clutch

Keyway Cam

Braking Action

Automatic braking action in the drum

Cable

28m of 8.1mm diameter

Fairlead

4-way roller fairlead

Battery

Recommended: 650CCA minimum for winching

Battery Leads

2 gauge,72"(1.83mm)

Finish

Powder coating

Weight

N.W. 34kgs  G.W 36kgs

Overall dimensions

(L*W*H) 526.3x160x179mm

Mounting Bolt Pattern

10” x 4.5” (254x114.3mm)

Line Pull

Lbs

NO

LOAD

2000

4000

6000

8500

kgs

909

1814

2721

3856

Line Speed

ft/min

25

17.91

12.30

10.33

8.54

m/min

9.45

5.46

3.75

3.15

2.05

Motor Current

amps

60

113

184

228

301

Layer of cable

1

2

3

4

Rated line

pull per layer

Lbs

8500

6620

5630

4850

Kgs

3856

2980

2534

2183

Cumulative

Cable capacity

Ft

23.3

47

80

92

M

7.1

14.5

24

28
