Catalogue

   Type

Parameters

Features

View by phone

Support monitoring via mobile devices on line(such as iOS、Android OS、Symbian OS、WindowsPhone7)

Mobile Platform

No need to install software, Multi-screen monitoring and managing by mobile phone,alarming,viewing.

View on PC

Internet Explorer 6.0 or higher version，firefox，chrome

Super Client

1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm

System

Operation system

Embedded Linux OS

System security

Supports three-level account, password, user multi-level authority management

DDNS

Provide DDNS for free ,like demo.gocam.so

Collection

Image sensor

1/4 inch 0.3MegaPixel Color CMOS Image Sensor

SNR

≥50dB

Minimum Illumination

0.3Lux

3A

Auto White Balance,Auto Exposure,Automatic Gain

Lens

Standard：12mm

Video

Compression Format

H.264

Resolution

VGA（640×480、QVGA(320×240)

Maximum frame rate

30fps

Bit Rate

128Kbps～1Mbps

Adjustment

light intensity,contrast ratio,saturation level are adjustable.

Nightvision

Filter Switch

Built in IRCUT，No color cast in day,clearer image at night

Effects

54 Φ5 LEDs     IR distance :40m

Network

Socket

RJ-45   10/100Mb   self-adaptable Ethernet slot

Protocol

TCP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPnP，RTSP，PPPoE , etc

WIFI

WIFI 802.11 b/g/n

Visitors Online

Support 10 visitors viewing on line at the same time

Audio

Encode formats

ADPCM

Input

one channel MIC input ,normal connector Of3.5mm

Output

one channel linear output,normal connector Of3.5mm

Memory

Memory Socket

Automatic pop-up slot for SD card

View by SD Card

Remote browsing, download of content from32Gtf card

P/T

Controlation

can connect to P/T in one way RS485 interface

Physical index

Power

DC 5V

Comsumption

<8W

Temperature

-10~75℃

Humidity

10%~85%

Weight

1700g

Package size

200mm x120mmx179mm（LxWxH）
