| 1. Main Technical Parameters | ||||
| Vehicle Model | CA4206P1 K2T3EA80 |
CA4253P1 K2T1EA80 |
CA4163P1 K2EA80 |
|
| Engine Model | CA6DL1-29E3 ;28E3F;31E3F |
CA6DL1-29E3 ;31E3F |
CA6DL1- 26E3/F |
|
| Rated power(hp) | 280,290,310 | 290,310 | 260 | |
| Gearbox | 9JS119、RT11509 | 9JS119; RT11509; RTOD-115 |
8JS118 | |
| Rear axle | 485;reinforced type drag rear axle | 457 | 457 | |
| Clutch | φ430 | φ430 | φ430 | |
| Cab | J5M, raised roof ,semi-floating | J5M,raised roof,lengthen 150 semi-floating | J5M,raised roof,semi-floating | |
| Tire Specification | 11.00R20 | 11.00R20 | 11.00R20 | |
| Wheelbase(mm) | 1700+2450 | 3350+1350 ;3150+1350 | 3400 | |
| drag loading | 35415、34015、37305 kg | 34400 ;37415kg | 31625 kg | |
| 2. Product Feature and Specification | ||||
| A | Aowei engine of Wuxi diesel, large rated power, low fuel consumption | |||
| B | light weight, save energy, excellent cost performance | |||
| C | advanced feature, have high reliability | |||
| D | hanway cab, safety and comfortable | |||
| E | 350L fuel tank, applied less stockpile fuel | |||
| F | various optional features | |||
