Performance characteristics:
High saturation magnetic induction, high magnetic permeability, low coercivity , low core loss,
excellent stability, can work a long time under -55~130°.
Application:
In a wide area such as a common mode chokes, differential mode filter inductor, high frequency s
witching power supply, high-frequency inverter, zero sequence transformer, magnetic
amplifiers, and many other electrical components. Fidelity is also the head high sensitivity,
highperformance magnetic amplifier, leakage protection switches and other components to instead of
Co-based amorphous, silicon steel, ferrite, permalloy soft magnetic materials.
Physical properties:
Saturate Induction | 1.56T | Hardness(Hv) | 960kg/mm2 |
Curie Temperature | 410 degress C | Density | 7.18g/cm3 |
Crystallization Temperature | 535 degress C | Resistivity | 130μΩ-cm |
Saturate Magnetostriction | 27×10-6 |
Magnetic properties:
Product type |
Transverse field annealed |
No field annealed |
Longitudinal field annealed |
Maximum permeability | >2×104 | >20×104 | >25×104 |
Saturate induction | 1.5T | 1.5T | 1.5T |
Remanence | <0.5T | 01.0T | 1.2T |
Coercivity | <4 A/m | <2.4 A/m | <4 A/m |
Core loss (50kHz, 1.4T) | <0.2 W/kg | <0.13 W/kg | <0.3 W/kg |
Core loss (400kHz, 1.2T) | <1.8 W/kg | <1.25 W/kg | <2 W/kg |
Core loss (8kHz, 1.0T) | <80 W/kg | <60 W/kg | <100 W/KG |
