Brand Name TICO POWER or OEM
1) Place of Origin Fujian, China (Mainland)
2) Price: FOB10,937-12,570USD/Set
3) Port: Fuzhou
4) Delivery Time: 25 Days
5) Payment Terms: L/C,T/T,by negotiation
6) Supply Ability: 100 Set/Sets per Month
7) Minimum Order Quantity: 1 Set/SetsTrial Order
8) Color Customer colors available
9) Contract Manufacturing: OEM Service Offered
10) Certification CE, EPA, ISO
===================================
Features
1) 12Months Quality Warrarry
2) Low fuel consumption
3) High quality promise
4) Color Customer colors available
5) Copper wire
===================================
Specification
Model: TC-H200S
Frequency (HZ): 60Hz
Nominal Power Output (KVA/KW): 225/180
Voltage (V): 220V/ 380V; 230V/ 400V
Phase number: Three phases
Power factor: 0.8
Generator
Model: TFWS274H
Type: Alternator
Power output: 180
Excitation system: Brushless excitation with AVR
Protection: IP22
Insulation class: H
Connection Type: SEA
Engine
Engine Model: R6120ZLD
Number of cylinder: 6
Bore*Stroke: 120x130
Displacement: 7.8L
Specific fuel consumption(g/kw.h): <228
Rated Speed(r/min): 1800
Nominal output (KW): 215
Starting System: Electric
Cooling method: Closed circle water-cooled
Starting battery: 12V/100AH*2
Average noise level db (A) 7m: 75db(A)
Cont working time (hrs): 12
Overall dimension (mm): 3600x1400x1655
Packing dimension: (mm): 3600x1450x1735
Net weight: 2610kg
Gross weight: 2700kg
