Introduction
CLP Controllers designed and manufactured by our company are suitable for automatic control of 12V/24V solar lamp system. The features of advanced technique, stable performance, protection system, waterproof etc have been recognized by our customers.
Functions
1. Manage
2. Automatically turn on & off solar lamps;
3. Harmonize the work of battery: Prevent battery from reverse discharging at the night;
4. Temperature compensation capability;
Specifications
Waterproof/Photoswitch/Time Switch:
|
Model: |
CLP05-3A/ST2 |
CLP05-5A/ST2 |
CLP12-10A/ST2 |
|
Rated Voltage: |
12V / 24V |
||
|
Rated Charging Current: |
3A |
5A |
10A |
|
Rated Load Current: |
3A |
5A |
10A |
|
Charge Stopping Voltage: |
14V/28V |
||
|
Power Supply Stopping Voltage: |
10.8V/21.6V |
||
|
Power Supply Resuming Voltage: |
11.8V/23.6V |
||
|
Photoswitch Mode: |
Visibility 20M |
||
|
Time Switch Mode: |
5hr, 6hr |
||
|
Time Switch Error |
+/-2% |
||
|
Working Temperature: |
-20~+60C |
||
|
Relative Humidity: |
<93% |
||
Photoswitch (non-waterproof):
|
Model: |
CLP15-5A/ST |
CLP15-10A/ST |
CLP15-12A/ST |
CLP15-15A/ST |
|
Rated Voltage: |
12V / 24V |
|||
|
Rated Charging Current: |
5A |
10A |
12A |
15A |
|
Rated Load Current: |
5A |
10A |
12A |
15A |
|
Charge Stopping Voltage: |
14V/28V |
|||
|
Power Supply Stopping Voltage: |
10.8V/21.6V |
|||
|
Power Supply Resuming Voltage: |
11.8V/23.6V |
|||
|
Photoswitch Mode: |
Visibility 20M |
|||
|
Working Temperature: |
-20~+60C |
|||
|
Relative Humidity: |
<93% |
|||
