Item NO:XCC
LCM Mode: COB LCD Module
Type:Character type (8 CHARACTERS X 1 LINE)
SPECIFICATION
Character Number |
8W x 1H |
--- |
Character size |
6.45X10.75 |
mm |
Overall Size |
84.0X44.0 |
mm |
Character pitch |
7.15 |
mm |
Viewing Area |
61.0X15.8 |
mm |
Dot size |
1.25 X1.30 |
mm |
Hole Hole |
79.0X36.0 |
mm |
Dot Pitch |
1.30X1.35 |
mm |
1. |
5x8 Dots with cursor |
2. |
Built-in controller (SPLC780D or Equivalent) |
3. |
+5.0V power supply (Also available for +3.0V) |
4. |
1/8 duty cycle |
5. |
BKL to be driven by PIN1,PIN2,or PIN15,PIN16,or A,K |
6. |
N.V. optional |
Display type: COB/COG Type, TN/STN/HTN/FSTN/CSTN/VA
Operating temperature: -20 to + 70 degree Celsius
Storage temperature: -30 to + 80 degree Celsius
Backlight: LED(white/green/yellow/amber/blue)
