Suitable for packing granule material or good flow property powder.Such as sugar,salt,washing powder,sesame,seeds,beans,rice,puffy goods and so on.
Standard Specification:
Principal packer model |
SK-420 |
Metering system |
Four heads linear electronic scale |
Material conveyor |
Simple material conveyor |
Sealing form |
Back sealing |
Air consumption |
|
Max. Film width |
Max |
Film thickness |
0.04 |
Film material |
OPP/CPP,OPP/CE,MST/PE/PET/PE |
Bag length |
80 |
Bag width |
80 |
Max. extend diameter of coiled material |
Max |
Packing speed |
5-60bag/min |
Power supply specification |
220V,50/60Hz,3KAV |
Feature:
1.This machine is with high precision structure for simple and easy operation and repair.
2.Two synchronous belt device and servomotor film transporting system, makes the film move stably and form bag smoothly.
3.Two independent sealing cylinders design, makes the excellent sealing and nice sealing stripes.
4.PLC system and large touch screen,high automatic ,simple operation and maintenance, it works with low noise and stable.
5.Adopt external film feeding mechanism. Film setting will be more easy and quick.
6.Adopt double vibration feeder,easy operation.
7.The stainless steel metering hoppers are easy to be discharge,easy for daily maintain.
8.This machine can finish from feeding,measuring,date printing,bag forming,filling,sealing,cutting,counting in one operation.
Optional devices:
1. Nitrogen gas flushing
2. Vacuum packing device
3. Flip device
4. Gusset device
5. Linking bag device
6. Hole punch device
7. Tear notch device
8. PE sealing system
9. Finished product conveyor
