Rubber Mixing Mill is traditional equipment; we have been committed to developing new structure of the machine for many years. Through technological improvement and application, we have obtained the breakthrough improvement in many aspects, such as motive force transmitting system, safety factor and so on. Lower cost, higher efficiency and more humanization of operating have always been our pursuit.
1. This mixing mill can be equipped with hydraulic or mechanical device which can automatically make the rubber material be mixed over and over again. So the labor intensity and mixing time can be reduced greatly.
2. The Rubber mixing mill speed reducer is Hardened speed reducer, it is low noise, high efficiency, good transfer effect.
3. To ensure the safety of staff and equipment, we install convenient button for emergency.
4. All the mixing mills we provide to you are checked after 3-7 hours non-stop full load operation, perfect quality and low noise. Customers can use them immediately after installation.
Mode |
XK-550B |
XK-660 |
Working Diameter of Rolls (mm) |
550 |
660 |
Working Length of Rolls (mm) |
1500 |
2130 |
Front Roll Surface Speed (m/min) |
27.94 |
28.6 |
Friction Ratio |
1:1.22 |
1:1.24 |
Max. nip |
15 |
15 |
Capacity per Batch(kg) |
50~60 |
165 |
Motor Power (KW) |
110 |
245 |
Dimensions: (L × W × H)(mm) |
5870×2475 |
7465×3662 |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() | |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
