1,1 roller temperature adjustment device: the quality rotary joint, high pressure hose, water pipe additional shut-off valve to facilitate equipment maintenance, with connection into the backwater pipe bluing, user-friendly plumbing connections.

1,2 roller: roller alloy chilled cast iron, the front and rear rollers can be made of hollow light roller, so as to achieve better temperature control effect work surface hardness of 68 ~ 72HSD

1,3 roller bearings: high-precision self-aligning roller bearings, using automatic lubrication system.

1,4 reducer: the ZSY series of square boxes Hardened reducer gear affordability, wear-resistant,

1,5 rack gland: welded steel plate processing after annealing treatment.

1,6 block plastic sheet: fixed-block plastic sheet steel.

1.7 emergency brakes: emergency stop button way, rack around with four emergency stop button.

1.9 Safety devices: Security chip breaking pressure 110 ± 3t, to protect the main parts from damage.

2. linear speed or the speed ratio of the front and rear rollers according to the production of different quality of reclaimed rubber adjusted.

Time and cost savings for customers, I produced the open kneader connected the wires between the motor and the control cabinet at the factory wires to the customers need to shop outside the control cabinet on can; open-kneading machine after the installation is completed, load test 4-6 hours to reduce debugging time and cost.
