Printing Method | Thermal Line | |
Printing Speed | 90mm/s or 20lines/s | |
Resolution |
8 dots/mm, 384 dots/line | |
Effective Printing Width | 48mm | |
Character | Character Set | IBM Character set II,GB2312-80(Chinese) |
Print Font | ANK: 12 ×24 Chinese: 24 × 24 | |
Character per Line | 32 | |
Paper Spec | Paper Type | Thermal paper |
Paper Width | 57.5±0.5mm | |
Paper Roll Diameter | Max: 83.0mm | |
Roll Core Inner Diameter | 13mm(min.) | |
Paper Thickness | 0.06 to 0.07mm | |
Paper Supply Method | Drop-in Paper Load | |
Reliability | MCBF(MCBF) Mean Cycles Between Failure |
5 million lines |
TPH | 100km | |
Barcodes | UPC-A,UPC-C,EAN-13,EAN-8,CODE39,ITF,CODEBAR,CODE93,CODE128 | |
. | ||
Driver | Windows98/2000/NT/XP | |
Emulation | ESC/POS | |
Drawer Port | 1 Port | |
Interface | RS-232, Parallel, USB, Ethernet | |
Power Supply (Adapter) | AC100 ~240V(±10%), DC 9V, 3A | |
Physical | Net Weight | 400g |
Gross Weight | 1.0kg | |
Printer Dimension (W×L×H) | 108 ×168 ×81mm | |
Application | Restaurants, Department Stores,Kitchen, Convenience Stores,Specialty Retail,Super market |
